Low Pressure Transducer, Stainless Steel, 0.5 – 4.5 V – Series 0675

$0.00

■ Output Signal: 0.5-4.5 V, (ratiometric)
■ Overpressure Protection: Up to 2,900 psi (200 bar)
■ Burst Pressure: up to 3,625 psi (250 bar)

Clear
Description

Description

Performance:

  • Stainless steel housing 1.4404 / AISI 316L, hex 22
  • Maximum Rise Rate: ≤ 14.5 psi/ms (≤1.0 bar/ms)
  • Wetted parts guarantee highest media compatibility in seawater or pharmaceutical industry applications

Advantages:

  • Specifically suitable for low pressure, including vacuum applications
  • High-sensitive Piezo-Resistive Sensor in the oil-filled housing guarantees high-accuracy, repeatability, and long-term stability
  • Different sealing materials allow for operations in a wide range of temperatures and media
  • Special versions (e.g. cleaned for oxygen Use) are available on request
  • Long life expectancy even under high pressure ramp rates
  • Standard or customized pressure ranges available
  • Built-in reverse polarity

Download

Download Data Sheet
Download Manual

0675-0680-0690-Final
Additional information

Additional information

Model Number

0675

Pressure Ranges

-1-1 bar (compound), 0-10 bar (0-145 psi), 0-4 bar (58 psi), 0-40 bar (0-580 psi), 0-1 bar (0-15 psi), 0-1-0 bar Vac (30 in Hg), 0-16 bar (0-200 psi), 0-100 bar (0-1,500psi), 0-6 bar (0-100 psi)
