Automotive Pressure Switches & Pressure Transducers
■ TE AMP Superseal 1.5® Connector
■ Overpressure Safety: Up to 4,350 psi
■ Field-adjustable pressure range: 1.45 to 725 psi
■ Vacuum Switch up to 42 V
■ SPST-NO or SPST-NC
■ Overpressure Safety: Up to 290 psi (35 bar)
■ Brass Housing
■ Deutsch DT04-3P Connector
■ Overpressure safety: Up to 1,450/5,801 psi
■ Field-adjustable pressure range: 4.35 to 1,450 psi
■ Diaphragm pressure switch
■ Brass Body (HEX 24mm / 0.95″)
■ SPST-NO or SPST-NC configuration options
■ Overpressure safety: Up to 500 psi (35 bar)
■ Pressure ranges to 1,500 bar (21,755 psi)
■ Excellent corrosion resistance
■ Silicon-on-sapphire sensor technology
■ ESI Part # GS4400 and GS4500
■ Silicon-on-sapphire sensor technology
■ Pressure ranges 0-500 mbar to 0-1,500 bar (0-7.5psi to 0-20,000psi)
■ High accuracy and performance
■ Pressure ranges up to 1,500 bar
■ Titanium wetted parts
■ High operating temperature up to 150°C (300°F)
■ Overpressure safety: Up to 8,700 psi
■ Field-adjustable pressure range: 725 to 2,175 psi
■ Zinc-plated Steel Body
■ Pressure ranges to 1,500 bar
■ Superior Thermal Performance: Stable readings in extreme heat
■ High Temperature Capability: Continuous operation up to 200°C (392°F)
■ Pressure measurement ranges up to 5,000 bar (72,500 psi)
■ Silicon-on-sapphire sensor technology, providing superior accuracy, thermal stability, and long-term reliability
■ Wetted parts constructed from titanium alloy for superior durability
■ Pressure Switch with Deutsch Connector DT04-3P
■ Overpressure Safety: Up to 8,700 psi
■ Field-adjustable pressure range: 725 to 2,175 psi
■ Low pressure measurement from 50 mbar
■ Low hysteresis and excellent long term stability
■ Robust stainless steel construction
■ Pressure transmitters specially for low pressures, including vacuum applications
■ Output Signal: 4-20 mA (2-wire)
■ Overpressure Protection: Up to 2,900 psi (200 bar)
■ Sample rate up to 1,000 Hz (1,000 readings per second)
■ Choice of pressure ranges from vac to 72,500 psi (5,000 bar)
■ USB 1.1 and USB 2.0 full speed compatible
