Description
Military Pressure Transducer – DWG 12259832
SUCO ESI DF6101 Series
SUCO ESI manufactures the DF6101 Series Pressure Transducer, designed to DWG 12259832 and engineered to meet the demanding requirements of U.S. military and defense applications. This compact, rugged pressure sensor is ideal for use in military vehicles and harsh operational environments where reliability and long service life are critical.
Performance Features
- Compact design suitable for military vehicles and defense platforms
- Fully sealed for ingress protection in harsh environments
- Stainless steel housing and sensing element
- High-level millivolt (mV) output signal
- Available in multiple pressure ranges
- Manufactured in accordance with ISO 9001:2015
- CAGE Code: 0TSK1
Military & Defense Advantages
The SUCO ESI North America DF6101 pressure transducer series has been designed and manufactured to meet the exacting requirements of military standards, delivering outstanding reliability and proven performance in the field. SUCO ESI has a long-established track record supplying defense and military programs where quality, durability, and compliance are mandatory.
Featuring a low-level millivolt output, these pressure transducers are constructed using materials that strictly conform to applicable MIL drawings and specifications. The rugged design provides exceptional environmental protection, even when exposed to fuel, engine lubricants, hydraulic fluids, shock, vibration, and extreme temperatures.
The latest sensing technology, combined with a robust mechanical design, ensures measurement stability, accuracy, and long-term performance in the most demanding military environments—supporting extended service life in the field.
Compliance & Quality Assurance
All DF6101 pressure transducers meet the technical and physical requirements outlined in the governing specification, including:
- Accuracy and stability
- Shock and vibration resistance
- Humidity and immersion
- High-temperature endurance
- Environmental protection and corrosion resistance
- Overpressure performance
SUCO ESI North America ensures every unit is fit for purpose through a 100% final inspection and testing protocol, with workmanship performed in accordance with relevant MIL standards. Products are fully checked for conformity and supplied with appropriate certification as standard.
| ESI Part Number | Part Number | NSN | Range |
|---|---|---|---|
| DF6101-4 | 12258932-4 | 6685-01-170-9956 | 0-25 psig |
| DF6101-6 | 12258932-6 | 6685-01-167-4298 | 0-100 psis |
| DF6101-9 | 12258932-9 | 6620-01-501-8648 | 0-30 psig |
| DF6101-10 | 12258932-10 | 6620-01-501-8649 | 0-100 psis |
Frequently Asked Questions (FAQ)
Are your pressure transducers MIL-Spec compliant?
Yes. SUCO ESI North America pressure transducers are designed to meet applicable MIL-Spec requirements and are suitable for use in U.S. military and defense applications.
Do your products have NSN (National Stock Number) support?
Yes. Many SUCO ESI North America pressure transducers and sensors are available with NSN support, enabling streamlined procurement through DoD and DLA supply chains.
Is SUCO ESI an approved U.S. government supplier?
Yes. SUCO ESI North America is a registered U.S. government contractor with CAGE Code 0TSK1, supporting military depots, prime contractors, and defense integrators.
What certifications do you hold?
ESI Technology operates under an ISO 9001:2015 certified quality management system, ensuring consistent quality, traceability, and compliance for mission-critical programs.
Do you offer custom pressure sensor solutions for defense programs?
Yes. We provide custom-engineered pressure transducers and sensing solutions to meet specific military and defense program requirements.
