■ Vacuum Switch up to 42 V
■ SPST-NO or SPST-NC
■ Overpressure Safety: Up to 290 psi (35 bar)
■ Brass Housing
■ Diaphragm pressure switch
■ Brass Body (HEX 24mm / 0.95″)
■ SPST-NO or SPST-NC configuration options
■ Overpressure safety: Up to 500 psi (35 bar)
■ Accuracy rating ≤ ±0.25 % of span BFSL
■ Output Signal: 0.5-4.5V ratiometric, 4-20mA, 0-5 VDC (3 wire), 0-10 VDC (3 wire)
■ Pressure ranges from 14.5 psi to 1,450 psi (0.5 bar to 100 bar)
■ Strain gauge technology
■ Pressure ranges 0-500mbar to 0-700bar (0-7.5psi to 0-10,000psi
■ Output options 0-20mVdc, 0-5Vdc, 0-10Vdc and 4-20mA
■ Pressure ranges to 1,500 bar (21,755 psi)
■ Excellent corrosion resistance
■ Silicon-on-sapphire sensor technology
■ Pressure ranges 0-1bar to 0-1,500bar (0-15psi to 0-21,000psi)
■ Titanium wetted parts
■ High operating temperature up to 150°C (300°F)
■ Piston pressure switches up to 42 V
■ Zinc-plated steel
■ Snap action with silver contacts
■ Overpressure safety: 10,152 psi (700 bar)
■ Silicon-on-sapphire sensor technology
■ Pressure ranges to 5,000 bar (72,500 psi)
■ 0-100mVdc, 0-5Vdc, 0-10Vdc or
4-20mA output
■ Pressure ranges to 5,000 bar (72,500 psi)
■ RS-485 communication up to 1200 m
■ High accuracy option
■ Sample rate software selection up to 1,000 Hz
■ Choice of pressure ranges from vacuum to 72,518 psi (5,000 bar)
■ Accuracy (NLHR) ±0.15% of span BFSL
■ Low pressure measurement from 50 mbar
■ Low hysteresis and excellent long term stability
■ Robust stainless steel construction
■ Overpressure safety: Up to 8,700 psi
■ Field-adjustable pressure range: 1.45…725 psi
■ SPST-NO or SPST-NC switch
■ Pressure ranges from 14.5 psi to 1,450 psi (0.5 bar to 100 bar)
■ Absolute, Gauge and Vacuum pressure ranges
■ Excellent corrosion resistance over a wide variety of industrial processes
■ 4-20mA two-wire output
■ Ranges 0-2.5 bar to 1,000 bar (15 psi to 15,000 psi)
■ Flammable gases (zone 0) and dusts (zone 20)
■ Sample rate up to 1,000 Hz (1,000 readings per second)
■ Choice of pressure ranges from vac to 72,500 psi (5,000 bar)
■ USB 1.1 and USB 2.0 full speed compatible
